POF 适配器 F05 单工 /4个
Fibre optic plug connector; F05; Coupling; Straight; Simplex; plug-in;
POF 适配器 F05 单工 /4个
SGD 28.69
/
POF 适配器 F05 单工 /4个
SGD 28.69
/
付款与安全
您的支付信息已安全处理。我们不存储信用卡详细信息，也无法访问您的信用卡信息。
Product characteristics
cold resistance
技术属性
一般信息
| Product type | Fibre optic connector |
| Scope of delivery | 4 couplings |
| Brand | HITRONIC® |
| Fibre optic cable type | POF |
| Installation type | plug-in |
| Delivery Unit | 4.000 |
| Weight | 0.002 kg |
电气特性
| Insertion attenuation (nominal) | 2.5 dB |
产品设计
| Connector housing angle | 180 |
| Total length | 18.2 |
| Design connector housing | Straight |
| Connector type | Coupling |
| Type of plug connection | F05 |
| Direct mounting possible |
|
| Bend protection boot |
|
| Coupling connection type | F05 |
| Connector colour | black |
| Overall width | 34 |
| Dust protection cap |
|
| Variant of connector | Simplex |
| Total height | 8.2 |
| Suitable type of optical fibre | Multi-mode fibre |
产品特点
| Max. storage temperature | 85 |
| Insertion attenuation | 2.5 |
| Storage temperature min. | -40 |
| UV-resistant |
|
| Operating temperature min. | -20 |
| Operating temperature max. | 70 |
认证和标准
| EAC certification number | Отказное письмо № 481 |
| EAC-certified | Not required |
文档
Downloads
Notes
- Photographs and graphics are not to scale and do not represent detailed images of the respective products.
- Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
产品系列列表
All articles from POF Adapter F05 simplex
| Article number | Scope of delivery |
|---|---|
| 29450099 | 4 couplings |
