电缆楔形夹具 FKK 08
Cable wedge clamp; Flat Cable Height (min./max.)2.0mm - 10.0mmPolyamide
电缆楔形夹具 FKK 08
SGD 17.20
/
电缆楔形夹具 FKK 08
SGD 17.20
/
付款与安全
您的支付信息已安全处理。我们不存储信用卡详细信息，也无法访问您的信用卡信息。
Product characteristics
cold resistance
halogen-free
技术属性
一般信息
| Product type | Cable wedge clamp |
| Delivery Unit | 1.000 |
| Weight | 0.103 kg |
电气特性
产品设计
| Number of cables | 2 |
| Overall width | 60.0 |
| Colour | orange |
| Minimum insertion depth of wedge | 60 |
| Total length | 99.0 |
| Min. flat cable height | 2.0 |
| Total height | 42.0 |
| Nom. flat cable width | 50.0 |
| Material | Polyamide |
| Flat cable height (max.) | 10.0 |
| Nom. flat cable height | 10.0 |
产品特点
| Clamping force (max.) | 800 |
| Halogenfree |
|
认证和标准
文档
Notes
- Photographs and graphics are not to scale and do not represent detailed images of the respective products.
- Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
- Trade product, not a LAPP product.
产品系列列表
All articles from FKK Flat cable wedge clamps
| Article number | For min. cable outer diameter | Imp 4cable outer diam min | Imp flat cable width nom | Nom. flat cable width | For max. cable outer diameter | Imp 4cable outer diam max | Imp flat cable height nom | Nom. flat cable height | Number of cables | Delivery Unit | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 52026050 | 90.0 | 17.0 | 3 | 1.000 | 0.349 kg | ||||||
| 52026051 | 50.0 | 10.0 | 2 | 1.000 | 0.103 kg |
